F3 – Setup Menu
Gem-5 User’s Manual 163
columns 5 and up, for example “Zone 76 Board Fault 2”. The log will label each
zone once in the case where zones have multiple faults. When printed, this report
includes more details and reverts to listing fault followed by list on zone numbers
with that fault.
Table 10 shows all the faults being logged. Note that Faults are set when detected
and are manually cleared on F4 – Fault screen via F2 = Clear Detector / Sum Zone
Faults or F4 = Clear All Faults. Faults are auto cleared when fault condition goes
away and the F3 – Setup, F4 – Out of Service Causes setting for that fault is
“WARN” or “AUTO” (also note that faults in use depend on model, installed options
and settings).
Table 10 Faults logged by SERVICE.CSV file
Fault logged in
SERVICE.CSV
Set
Manual
Clear
Auto Clear
Out of Service
Causes
Detector / Zone Faults
Low Bkg Rate √ √ √ NO,YES,AUTO
Excessive Bkg Rate √ √ √ NO,YES,AUTO
HV Out of Range √ √ n/a YES
Live Time Error √ √ n/a YES
Contaminated
High Bkg Rate √ √ √ NO,YES,WARN,AUTO
High Count Time √ √ √ NO,YES,WARN,AUTO
Due for Recalibration √ √ n/a NO,YES,WARN
Verification Failed √ √ n/a NO,YES
Due for Alarm Test
12
√ √ n/a
NO,YES
(After 1 to 3653 Days)
Carrier Board Fault √ √ n/a YES
Sensor Board Fault √ √ n/a YES
Auxiliary Sensor Board Fault √ √ n/a YES
Conditional Service Allowed
Elapsed
√ √ n/a 0 to 7 days
Temperature HOT √ √ n/a NO,YES
+12V Fault √ √ n/a NO,YES
Badge Reader √ √ √ NO,YES,AUTO
12
The monitor can be placed in service for 1 day from the time the fault is cleared without regenerating this particular fault
in order to perform the alarm test.
