4.3.6 Memory Menu — MEM Key
The memory menu contains functions for storage of programs and screen images.
Various editing functions are provided in this menu for previewing stored (saved)
data, recalling stored data, editing file names, adding notes, setting a reference image,
and erasing stored data.
The NORTEC 600 is capable of storing and retrieving complete instrument setups. By
default, the data is saved with the date, time, and instrument-generated file name. If a
PowerLink probe remains connected when the data is stored, the probe part number
and description are also recorded. After the data is stored, the file name can be
changed by using up to 29 alphanumeric characters, and notes can be added to the
file. Changes to the file name and notes are made using the front panel of the
instrument, or alternatively, by using the NORTEC PC software (included with each
instrument).
Whenever a program (stored data file) is recalled, the currently active instrument
settings are overwritten and cannot be recovered, unless these settings were
previously stored in another program location.
The following memory storage, or MEM ( ), functions are available:
PREVIEW
Used to view instrument screen images that were captured at the moment the
data was saved.
To preview a stored data file, press the MEM menu key ( ), rotate the knob
until the desired data file is highlighted, and then press the A key. The instrument
screen image that was stored at the time the data file was saved will appear on the
instrument screen. The following steps can be taken:
— Exit (return to the previous menu) by pressing the A key.
— Recall the stored data file by pressing the B key.
— Set the data file as a reference image by pressing the D key.
— Show or hide readings by pressing the C key (see Figure 4-13 on page 93 and
Figure 4-14 on page 93).
