DMTA-10040-01EN, Rev. E, February 2018
Chapter 5296
Figure 5‑243 Alarm polarity
2. Press the D key to highlight the alarm DWELL time, and then use the knob to
adjust the DWELL time to the desired value (0.0 s to 10.0 s, in 0.2 s intervals).
3. Press the E key and then rotate the knob to the desired alarm HORN value (ON
or OFF).
4. Press the ALARM menu key ( ) to access the ALARM 1 menu.
5. Press the A key to highlight the alarm SHAPE, and then use the knob to select
SWEEP.
6. Press the B and C keys to alter the TOP and BOTTOM alarm levels.
7. If necessary, press the ALARM menu key ( ) to access and adjust ALARM 2
or ALARM 3.
