DMTA-10040-01EN, Rev. E, February 2018
Chapter 144
1.6.2.3 microSD and USB Port
On the right-hand side of the NORTEC 600, a door covers the microSD slot and the
USB port (see Figure 1-23 on page 44). The I/O door closes against an integral
membrane seal to keep liquids away from the unsealed connectors behind the door.
The NORTEC 600 utilizes 2 GB microSD memory cards for both onboard and
removable memory. The onboard 2 GB microSD card is mounted on the PC board
inside the instrument, and is responsible for all onboard data storage. In the event the
instrument is damaged beyond repair, this microSD card can be removed at an
authorized service center, allowing you to recover critical data from the damaged
instrument.
The NORTEC 600 allows the user to connect the instrument to a PC via the USB port.
PC communication requires the interface program (Olympus P/N: N600-CD
[U8030151]) provided with the instrument for file transfers. The NORTEC 600 can
also communicate directly with other SPC programs.
Figure 1‑23 The microSD slot and USB port
The I/O door is kept closed by two thumb screws. You can also use a coin or a
screwdriver to manipulate these thumb screws as needed.
USB port
Thumb screws (two)
microSD card slot
