DMTA-10040-01EN, Rev. E, February 2018
Chapter 134
2. Loosen the two thumb screws, and then open the NORTEC 600 I/O door (see
Figure 1-13 on page 34).
Figure 1‑13 Installing the microSD card
3. Hold the card so that the microSD label faces toward the rear of the instrument.
4. Gently slide the card into the microSD slot until it clicks.
To remove the microSD card, gently push the card into the instrument and release. A
spring-loaded mechanism will partially eject the card, and then you can grasp the
card and remove it from the instrument.
1.6 NORTEC 600 Hardware Features
The NORTEC 600 instrument has many physical features that are either completely
new or improvements of features on older NORTEC 500 models. It is important to
become familiar with the use and maintenance of these items.
USB port
Thumb screws (two)
microSD card slot
microSD card
