DMTA-10040-01EN, Rev. E, February 2018
Chapter 5192
FULL NEXT key ( ) four times and set the RDG2 TYP to OFF. When done,
press the Return key ( ).
The list of dual frequency parameters is shown in Figure 5-99 on page 192.
Figure 5‑99 The list of dual frequency parameters
To calibrate the signals
1. Press the MAIN FILTER menu key ( ) once, and then set the FREQ (A key)
value to 3.0 kHz using the knob.
2. Press the MAIN FILTER menu key ( ) again, and then set the FREQ 2 (A key)
value to 1.0 kHz.
3. Place the probe on position 1 of the standard (see Figure 5-100 on page 193), and
then, while firmly pressing the probe on the standard, press the A-LIFT NULL
key ( ).
