DMTA-10040-01EN, Rev. E, February 2018
Instrument Overview 27
Figure 1‑6 Location of the NORTEC 600 power button and indicator light
1.4.1 Charger/Adaptor
A NORTEC 600 charger/adaptor is provided with every instrument. This
charger/adaptor is the primary method for powering the NORTEC 600, with or
without a battery installed. It is also used to charge the lithium-ion rechargeable
battery when it is installed in the instrument. A charger/adaptor indicator light on the
front panel of the unit displays the current status of the charger/adaptor (see
Figure 1-6 on page 27 and Figure 1-7 on page 27).
Figure 1‑7 The charger/adaptor indicator light on the front panel
Use only the power cord supplied with your instrument, unless specifically instructed
in the manual. Using an unauthorized power cord may result in damage to
instruments or serious injury to the user.
Charger/adaptor
indicator light
Power button
