Always use combined horizontal and vertical gain (H/V GAIN).
Figure 5‑237 Adjusting the gain
5. Press the FREEZE key ( ) to enable signal acquisition.
If you adjust your instrument settings in this manner, you can size the defect using the
VMAX display on the instrument, as shown in the images of Figure 5-238 on
page 291.
