Olympus nortec 600 - 4 Control Functions; Powerlink; Figure 4-1 the Powerlink Recognition Screen

DMTA-10040-01EN, Rev. E, February 2018
Control Functions 69
4. Control Functions
This chapter provides explanations of the NORTEC 600 instrument control functions.
4.1 PowerLink
The PowerLink feature enables the NORTEC 600 eddy current instrument to
automatically recognize Olympus PowerLink probes and rotating scanners when they
are connected to the instrument. The instrument is then configured according to the
parameters programmed into the PowerLink ID chip. Each PowerLink probe is
programmed at the factory to identify itself based on the model number, preselected
operating frequency, gain, and serial number.
When a PowerLink probe or rotating scanner is connected, the instrument displays
the PowerLink recognition screen (see Figure 4-1 on page 69).
Figure 4‑1 The PowerLink recognition screen
