4.4.6 Display Menu in Dual Frequency — DISP Key
The display menu contains menus to control various functions such as DSP MODE
(display mode) CHANNEL, POSITION, H POS and V POS (horizontal and vertical
position), D ERASE (display erase), PERSIST, GRID, and ZOOM.
DSP MODE (display mode)
When dual frequency is enabled, five display modes are available on the
NORTEC 600 instrument: IMP (impedance), ALL‑IN‑1 (all in one), DUAL IMP
(dual impedance, also named “split screen”), SWP + IMP (sweep + impedance)
and SWEEP.
To choose the DSP MODE (display mode), press the DISP menu key ( ),
followed by the A key. With DSP MODE highlighted, rotate the knob to select the
desired mode.
IMP (impedance)
Impedance mode is the most common display mode. It incorporates a 10 × 10
grid configuration on the screen. The eddy current signal is shown moving
horizontally and vertically.
ALL‑IN‑1
ALL‑IN‑1 mode is used to display the signal traces associated with both
FREQ 1, FREQ 2, and the MIX signal at the same time, each with a different
color to show how the individual signals interact.
DUAL IMP (dual impedance)
Dual impedance (split screen) mode divides the instrument screen into two
impedance displays with channel 1 on the left and channel 2 on the right. The
dual impedance screen is used to set up dual frequencies, and it displays
FREQ 1 (frequency 1) and FREQ 2 (frequency 2).
SWP + IMP (sweep + impedance)
Sweep + impedance mode is similar to dual impedance mode except that the
instrument sweep display is shown on the left screen and the impedance
display on the right. As with the DUAL IMP (dual impedance) mode, it is
used to set up dual frequencies, and it displays FREQ 1 (frequency 1) and
FREQ 2 (frequency 2).
SWEEP
Commonly used with rotating scanners. The eddy current signal is shown
moving horizontally at a fixed rate across the screen. In dual frequency mode,
