Instrument Overview 37
Figure 1‑16 The NORTEC 600 front panel with SmartKnob and keypad
1.6.1.2 Keypad
The NORTEC 600 is available with an English, Chinese, Japanese, or international
keypad configuration (see Figure 1-17 on page 38 to Figure 1-20 on page 39, and
Table 4 on page 40). The text labels on some keys may be replaced by pictograms,
depending on the keypad configuration. In this document, keys are referred to using
the English label, which indicates its function. The keys are used to select menu items
or screen parameters and to change parameter values.
Direct-function
keys
Function keys
Charger/adaptor
indicator
Power button
Display window (screen)
SmartKnob
Menu keys
FULL NEXT key
To Next Page
