DMTA-10040-01EN, Rev. E, February 2018
Chapter 254
2.2 Selecting from the Menus
The NORTEC 600 menu keys at the bottom of the front panel are MAIN FILTER
( ), DISP ( ), ALARM ( ), MEM ( ), and ADV SETUP ( ). These
keys provide access to the operation menu. This menu appears at the right-hand side
of the screen (see Figure 2-5 on page 53). If applicable, pressing a menu key again will
display a secondary menu with parameters available for that key.
To select from a menu
1. Press one of the menu keys located at the bottom of the front panel to display a
menu: MAIN FILTER ( ), DISP ( ), ALARM ( ), MEM ( ), or
ADV SETUP ( ).
Pressing the same menu key again will cycle through the available options and
update the available functions which can then be adjusted.
2. Select the function to be changed by pressing the function key (A, B, C, D, or E)
located next to the function, which highlights the selected function.
Rotating the knob changes the function‘s value. The value selected with the knob
is automatically entered.
2.3 Displaying All Functions Simultaneously — ALL SETTINGS Menu
As an alternative to the operation menu, the NORTEC 600 has the option of
displaying all functions simultaneously using the ALL SETTINGS menu. The ALL
SETTINGS menu consists of three main elements: the title bar, the parameters, and
the help text (see Figure 2-6 on page 55).
