DMTA-10040-01EN, Rev. E, February 2018
Instrument Overview 35
1.6.1 Hardware Overview
Figure 1-14 on page 35 and Figure 1-15 on page 36 show the main components on the
NORTEC 600 instrument.
Figure 1‑14 Overview of the NORTEC 600 hardware — Front view
Protective rubber bumpers
D-rings to attach the
optional chest harness
(at the four corners)
Display window
(screen)
Keypad
Knob (SmartKnob)
