DMTA-10040-01EN, Rev. E, February 2018
Chapter 5276
Figure 5‑216 The 40 % OD and 60 % OD flaws set as a reference image
11. Place the probe in a defect-free area of the calibration standard near the 20 % OD
flaw, and then press the NULL foot switch.
12. Press the FULL NEXT key ( ).
13. Scan the entire length of the tube.
The scan result is shown in Figure 5-217 on page 276.
Figure 5‑217 The scan of the entire length of the tube
