Olympus nortec 600 - 6.10 Backing up the NORTEC 600 Files; Figure 6-28 the Microsd Card Location

DMTA-10040-01EN, Rev. E, February 2018
NORTEC PC Software 325
6.10 Backing Up the NORTEC 600 Files
The NORTEC PC software enables you to easily back up and clone your NORTEC 600
files. The backup file is stored externally on the microSD memory card of the
NORTEC 600 being backed up.
To back up a NORTEC 600
1. Connect the PC to the instrument using a USB cable.
2. Make sure that a microSD card is inserted into the microSD card of the
NORTEC 600 (see Figure 6-28 on page 325).
Figure 6‑28 The microSD card location
3. On the NORTEC PC software Utilities menu, select Backup (see Figure 6-29 on
page 326).
The Backup dialog box appears (see Figure 6-30 on page 326).
USB port
microSD card slot
microSD card
