DMTA-10040-01EN, Rev. E, February 2018
Chapter 124
Figure 1‑2 The NORTEC 600 connections
Use only the AC power cord supplied with your instrument, unless specifically
instructed in the manual. Using an unauthorized power cord may result in damage to
instruments or serious injury to the user.
The DC power, PROBE, and BNC connectors are located on the top end of the
NORTEC 600 (see Figure 1-3 on page 24).
Figure 1‑3 The top end connectors
To power
outlet
DC power plug
EP-MCA-X
charger/adaptor
AC power cord
USB to PC
microSD card
DC power connector
PROBE connector
(16-pin LEMO)
BNC connector
