1.4.2 Battery Compartment
The NORTEC 600 battery compartment cover allows you to quickly access the battery
(or AA batteries in the alkaline battery holder) without the need for tools. Two thumb
screws on the battery compartment cover secure it to the instrument case and ensure
the compartment is sealed.
The battery compartment cover also has a small hole in the bottom center area that is
covered on the inside by an environmentally sealed membrane vent. This vent is a
safety feature that is required in the event that the instrument battery fails and emits
gas. This vent must not be punctured.
Figure 1‑10 The battery compartment
Green Yes
Charger/adaptor is connected, but
no battery is installed.
OR
Internal battery is fully charged.
Table 3 Charger/adaptor and battery indicators (continued)
Charger/adaptor
indicator light
AC line power
connected
Indicator meaning
Battery
indicator
Membrane vent
hole
Thumb screws (two)
Battery compartment
cover
