DMTA-10040-01EN, Rev. E, February 2018
Chapter 5160
5.1.7 Inspecting Aircraft Wheels — All NORTEC 600 Models
This section contains an example procedure for inspecting aluminum aircraft wheels.
Inspection materials are shown in Figure 5-53 on page 160.
Figure 5‑53 Materials—aircraft wheels
The following products are used in this procedure:
• Special-purpose aircraft wheel inspection probe; P/N: WP-3-1537-L
• Cable: 1.83 m (6 ft) length, bridge coil configuration, 16 pin LEMO to
Fischer/LEMO triaxial (SPO-6472). P/N: 9122244 [U8800091]
• Special-purpose aircraft wheel inspection standard; P/N: WS-3-1537
Any wheel probe with matching standard can be used for this application.
To set the initial NORTEC 600 configuration
1. Connect the probe and the cable to the PROBE connector on the NORTEC 600.
