DMTA-10040-01EN, Rev. E, February 2018
Chapter 126
Figure 1‑5 The VGA OUT and I/O connectors
1.4 Power Requirements
The NORTEC 600 is designed to operate using three power supply methods:
• Directly from the NORTEC 600 charger/adaptor
• Internal lithium-ion battery
• Internal alkaline battery holder
Press the power button ( ) to turn on the NORTEC 600 (see Figure 1-6 on page 27).
Pressing this button once causes an initial beep, which is followed by the instrument
startup screen, and then a second beep approximately five seconds later.
VGA OUT connector
I/O connector
