DMTA-10040-01EN, Rev. E, February 2018
Instrument Overview 45
Do not expose the instrument to harsh and wet environments while the I/O door is
open. To prevent connector corrosion and damage to the instrument, keep the I/O
door closed and sealed when no cable is connected.
1.6.3 Various Hardware Features
The NORTEC 600 instrument’s physical features make it suitable for a variety of
operating environments.
1.6.3.1 Instrument Stand
The NORTEC 600 features an articulating stand for variable viewing angles (see
Figure 1-24 on page 45). The stand is attached to the back of the instrument with two
hard pivot blocks. There is a high-friction coating on the stand surface to help prevent
it from sliding. The stand is bent in the center to easily accommodate being placed on
a curved surface.
Figure 1‑24 Instrument stand
CAUTION
