DMTA-10040-01EN, Rev. E, February 2018
Using the Instrument 277
5.4.4.2 Using the Overlay Display
The remote-field curve is an alternative overlay display available on the
NORTEC 600. To use this display, you must save a calibration setup and then rename
the calibration setup file after it has been created.
To use the overlay display
1. Perform and then save a calibration by pressing the REF SAVE ( ) key.
2. Press the MEM menu key ( ).
3. Use the knob to select the calibration file you just created.
By default, the NORTEC 600 saves the file with a time/date stamp.
4. Press EDIT (C key).
5. Use the text editor to rename the file as follows: RFT_CURVE (see Figure 5-218 on
page 277). (Use the knob to select characters and the FULL NEXT key ( ) to
confirm each character.)
Figure 5‑218 Renaming the file
6. Press to accept the file name.
7. Press the ADV SETUP menu key ( ), followed by APL SELECT (application
select, A key).
