DMTA-10040-01EN, Rev. E, February 2018
Using the Instrument 147
Figure 5‑38 The scanning motions
3. Practice your weld inspection; for example, by using an optional weld sample,
such as Olympus P/N: WLD SAMPLE [U8860581].
The list of all parameters is shown in Figure 5-39 on page 148.
Key (for images at left and right):
1. Probe direction
2. Imperfection
3. Optimum angle to meet the varying surface condition
