DMTA-10040-01EN, Rev. E, February 2018
Instrument Overview 25
Do not allow metallic or foreign objects to enter the device through connectors or any
other openings. Otherwise, an electric shock or malfunction may result.
The USB port and the removable microSD memory card slot are located on the right-
hand side of the instrument, hidden behind the input/output (I/O) door (see
Figure 1-4 on page 25).
Figure 1‑4 The connectors behind the input/output (I/O) door
The I/O and the VGA OUT connectors are located at the back of the instrument, in the
upper section (see Figure 1-5 on page 26). A rubber cover protects each connector.
USB port
microSD card slot
I/O door
Removable
microSD card
