DMTA-10040-01EN, Rev. E, February 2018
Software User Interface 51
Figure 2‑3 The PowerLink recognition screen
To navigate the application menu for PowerLink
 In the PowerLink recognition screen, load the program stored in the PowerLink
probe by pressing the A key.
You can use the KEEP LAST SETTINGS function to load the previous
parameters if they are compatible with the probe or accessory that is detected.
This automatically sets up the instrument.
OR
 Bypass the stored program in the probe and gain access to the instrument’s main
inspection screen by pressing the Return key ( ).
2.1.2 Main Inspection Screen
After the initial steps are completed through the quick-setup menu or PowerLink
menu, the main inspection screen is displayed (see Figure 2-4 on page 52).
