DMTA-10040-01EN, Rev. E, February 2018
Chapter 494
EDIT
Enables editing of the file name and adding user FILE NOTES (text) to the stored
data.
To edit text (FILE NAME or FILE NOTE) of a stored data file, press the MEM
menu key ( ), rotate the knob until the desired data file is highlighted, and then
press the C key; a text editor screen will appear on the instrument display.
For more information, see “Memory Text Editor” on page 96.
SET REF (set reference image)
Allows the screen image that was stored with the data file to be displayed on the
present instrument screen (in a contrasting color) while performing inspections.
The displayed image cannot be erased until the SET REF function is turned off.
To display a reference image, press the MEM menu key ( ), rotate the knob
until the desired data file is highlighted, and then press the D key. Alternatively, a
reference image may be created using the current screen image by pressing and
holding the REF SAVE direct-function key ( ) until the instrument sounds a
“beep.”
To turn off a reference image, press the MEM menu key ( ), and then press the
Dkey.
An error message will appear when turning on the SET REF (set reference) function if
the selected DSP MODE (display mode) is not compatible with the currently active
DSP MODE.
For example, an error message occurs when the SET REF image being activated
contains a stored image with a DSP MODE setting of SWP+IMP, if the current mode
is IMP.
ERASE
Erases the selected program number (stored data file).
To erase a stored data file, press the MEM menu key ( ), rotate the knob until
the desired data file is highlighted, and then press the E key.
