Figure 15-129. Example of Contents of Registers for UART Reception of UART
(UART0, UART1) (2/2)
(e) Serial output register m (SOm) … The register that not used in this mode.
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
SOm
0 0 0 0 0 0
CKOm1
×
CKOm0
× 0 0 0 0 0 0
SOm1
×
SOm0
×
(f) Serial output enable register m (SOEm) …The register that not used in this mode.
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
SOEm
0 0 0 0 0 0 0 0 0 0 0 0 0 0
SOEm1
×
SOEm0
×
(g) Serial channel start register m (SSm) … Sets only the bits of the target channel to 1.
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
SSm
0 0 0 0 0 0 0 0 0 0 0 0 0 0
SSm1
0/1
SSm0
×
Caution For the UART reception, be sure to set the SMRmr register of channel r that is to be paired with
channel n.
Remarks 1. m: Unit number (m = 0, 1), n: Channel number (n = 1), mn = 01, 11
r: Channel number (r = n − 1), q: UART number (q = 0, 1)
2. : Setting disabled (set to the initial value)
×: Bit that cannot be used in this mode (set to the initial value when not used in any mode)
0/1: Set to 0 or 1 depending on the usage of the user
