RL78/F13, F14 CHAPTER 9 REAL-TIME CLOCK
R01UH0368EJ0210 Rev.2.10 671
Dec 10, 2015
9.3.12 Week count register (WEEK)
The WEEK register is an 8-bit register that takes a value of 0 to 6 (decimal) and indicates the count value of weekdays.
It counts up in synchronization with the day counter.
When data is written to this register, it is written to a buffer and then to the counter up to 2 operating clocks (f
RTC) later.
Set a decimal value of 00 to 06 to this register in BCD code.
Set the WEEK register by an 8-bit memory manipulation instruction.
Reset signal generation clears this register to 00H.
Figure 9-13. Format of Week Count Register (WEEK)
Address: FFF95H After reset: 00H R/W
Symbol 7 6 5 4 3 2 1 0
WEEK 0 0 0 0 0 WEEK4 WEEK2 WEEK1
Cautions 1. The value corresponding to the month count register (MONTH) or the day count register
(DAY) is not stored in the week count register (WEEK) automatically. After reset release,
set the week count register as follow.
Day WEEK
Sunday 00H
Monday 01H
Tuesday 02H
Wednesday 03H
Thursday 04H
Friday 05H
Saturday 06H
2. When it reads or writes from/to the register while the counter is in operation (RTCE = 1),
see 9.4.3 Reading/writing real-time clock and follow the described procedures.
