Renesas RL78 Series User Manual

RL78/F13, F14 CHAPTER 13 D/A CONVERTER (RL78/F14 Only)
R01UH0368EJ0210 Rev.2.10 769
Dec 10, 2015
13.3.4 D/A Converter Mode Register 2 (DAM2)
When the P80/ANO0 pin is in use to output analog signal from the D/A converter, this register is used to control the output
from the ANO0 pin. When setting bits 5 and 4 (CVRS1 and CVRS0) in the comparator I/O select register (CMPSEL) to 10B
(internal reference voltage (DAC output) is selected), set the ANO0EN bit in this register to 0 (analog output is disabled).
Set the DAM2 register by a 1-bit or 8-bit memory manipulation instruction.
Reset signal generation clears this register to 00H.
Figure 13-5. Format of D/A Converter Mode Register 2 (DAM2)
Address: F0227H After reset: 00H R/W
Symbol 7 6 <5> <4> 3 2 1 0
DAM2 0 0 0 0 0 0 0 ANO0EN
ANO0EN Analog output (ANO0) control R/W
0 Disables analog output (ANO0). R/W
1 Enables analog output (ANO0).
