RL78/F13, F14 CHAPTER 4 PORT FUNCTIONS

R01UH0368EJ0210 Rev.2.10 332

Dec 10, 2015

4.3.11 Peripheral I/O redirection register 2 (PIOR2)

This register is used to specify whether to enable or disable the peripheral I/O redirect function.

PIOR2 enables or disables redirection of the timer array unit functions; that is, it specifies which I/O port is assigned to

each input pin of timer array unit 1.

This register can be set by an 8-bit memory manipulation instruction.

Reset signal generation clears this register to 00H.

Figure 4-84. Format of Peripheral I/O Redirection Register 2 (PIOR2)

Address: F0018H After reset: 00H R/W

Symbol 7 6 5 4 3 2 1 0

PIOR2 PIOR27 PIOR26 PIOR25 PIOR24 PIOR23 PIOR22 PIOR21 PIOR20

Bit Function 100-pin 80-pin

Setting value Setting value

0 1 0 1

PIOR27 TI17 P71 P57 P71

Note 1

P57

Note 1

PIOR26 TI16 P32 P65 P32

Note 1

P65

Note 1

PIOR25 TI15 P70 P56 P70

Note 1

P56

Note 1

PIOR24 TI14 P31 P64 P31

Note 1

P64

Note 1

PIOR23 TI13 P10 P55 P10

Note 2

P55

Note 2

PIOR22 TI12 P11 P46 P11

Note 2

P46

Note 2

PIOR21 TI11 P12 P54 P12

Note 2

P54

Note 2

PIOR20 TI10 P41 P45 P41

Note 2

P45

Note 2

Notes 1. Group E products only

2. Products of Groups B to E only

Caution The 64-, 48-, 32-, 30-, and 20-pin products do not have the PIOR2 register.
