18.3.58 CANi Transmit/Receive FIFO Message Lost Status Register (CFMSTS) (i = 0)
Address CFMSTS: F0361H
b7 b6 b5 b4 b3 b2 b1 b0
— — — — — — — CF0
MLT
After Reset 0 0 0 0 0 0 0 0
Bit Symbol Bit Name Description R/W
7-1 — Reserved These bits are always read as 0. R
0 CF0MLT CANi Transmit/Receive FIFO Buffer
k Message Lost Status Flag
0: No CANi transmit/receive FIFO buffer k message is
lost.
1: A CANi transmit/receive FIFO buffer k message is
lost.
R
The CFMSTS register is cleared to H'00 in global reset mode.
• CF0MLT Flag
The CF0MLT flag is set to 1 when the CFMLT flag in the CFSTSk register is set to 1 (a transmit/receive FIFO
message is lost). When the CFMLT flag is cleared to 0, the CF0MLT flag is cleared to 0.
