Renesas RL78 Series User Manual

RL78/F13, F14 APPENDIX A RELATED PRODUCTS
R01UH0368EJ0210 Rev.2.10 1840
Dec 10, 2015
APPENDIX A RELATED PRODUCTS
A.1 List of Analog and Power Devices
(1/2)
Field of
application
Analog and power device Related product Feature
Lightning
Lamp drive IPD
LED headlight power
switch
 PD166009T1F
40 V/10 m, protection function, overcurrent sensor, battery
reverse connection protection, low power supply voltage off hold
 PD166010T1F
40 V/10 m, protection function, high-precision load current
sensor, battery reverse connection protection, low power supply
voltage off hold
 PD166011T1J
40 V/25 m, dual channel, protection function, high-precision
load current sensor, low power supply voltage off hold
 PD166013T1J
40 V/60 m, dual channel, protection function, high-precision
load current sensor, low power supply voltage off hold
 PD166014T1K
40 V/60 m, quad channel, protection function, high-precision
load current sensor, low power supply voltage off hold
 PD166017T1F
40 V/6 m, protection function, high-precision load current
sensor, battery reverse connection protection, low power supply
voltage off hold
 PD166020T1F
42 V/10 m, protection function, high-precision load current
sensor, battery reverse connection protection, low power supply
voltage off hold
 PD166021T1F
42V/10m, protection function, high-precision load current
sensor, battery reverse connection protection, low power supply
voltage off hold, overheating shutoff latch
Interior lamp drive thermal
FET
HAF2017 60 V/43 m, LDPAK, overheating protection function
HAF2011 60 V/20 m, LDPAK, overheating protection function
HAF2007 60 V/75 m, DPAK, overheating protection function
Voltage step-up MOSFET NP22N055SLE 55 V/37 m, Ciss = 1100 pF, TO-252
NP32N055SLE 55 V/24 m, Ciss = 2000 pF, TO-252
NP40N055KLE 55 V/23 m, Ciss = 1950 pF, TO-263
NP40N10VDF 100 V/26 m, Ciss = 2400 pF, TO-252
NP70N10KUF 100 V/17 m, Ciss = 3750 pF Typ.@10 V, TO-263
Battery reverse connection
protection/
Abnormal current cutoff
MOSFET
NP36P04SDG 40 V/17 m, TO-252
NP36P04KDG 40 V/17 m, TO-263
Battery reverse connection
protection MOSFET
NP55N04SUG 40 V/6.5 m, TO-252
NP55N03SUG 30 V/5.0 m, TO-252
Flyback converter drive
MOSFET
NP82N10PUF 82 V/15 m, TO-263
NP70N10KUF 100 V/20 m, TO-263
For the sales situation and detailed specifications, contact your local sales representatives.
