Renesas RL78 Series User Manual

RL78/F13, F14 CHAPTER 36 ELECTRICAL SPECIFICATIONS (GRADE Y)
R01UH0368EJ0210 Rev.2.10 1822
Dec 10, 2015
36.5.3 On-chip Debug (UART)
(TA = -40 to +150C, 2.7 V  EVDD0 = EVDD1 = VDD  5.5 V, VSS = EVSS0 = EVSS1 = 0 V)
Parameter Symbol Conditions MIN. TYP. MAX. Unit
Transfer rate - 115.2 k 1 M bps
36.5.4 LIN/UART Module (RLIN3) UART Mode
(T
A = -40 to +150C, 2.7 V  EVDD0 = EVDD1 = VDD  5.5 V, VSS = EVSS0 = EVSS1 = 0 V)
Parameter Symbol Conditions MIN. TYP. MAX. Unit
Transfer rate -
Operation mode,
HALT mode
LIN communication clock source
(f
CLK or fMX):
4 to 24 MHz
4000 kbps
SNOOZE mode
LIN communication clock source
(f
CLK):
1 to 24 MHz
FRQSEL4 = 0 in the user option
byte (000C2H/020C2H)
4.8
LIN communication clock source
(f
CLK):
1 to 24 MHz
FRQSEL4 = 1 in the user option
byte (000C2H/020C2H)
2.4

Renesas RL78 Series Specifications

General

Core	RL78
CPU Clock Speed	Up to 32 MHz
Flash Memory	Up to 512 KB
RAM	Up to 32 KB
Operating Voltage	1.6 V to 5.5 V
Low Power Modes	HALT, STOP, SNOOZE
CPU Architecture	16-bit
Temperature Range	-40°C to +85°C
Package	LQFP
Timers	16-bit timers
Communication Interfaces	UART, I2C, LIN
A/D Converter	12-bit
