Renesas RL78 Series

RL78/F13, F14 CHAPTER 18 CAN INTERFACE (RS-CAN LITE)
R01UH0368EJ0210 Rev.2.10 1353
Dec 10, 2015
18.3.57 Receive FIFO Message Lost Status Register (RFMSTS)
Address RFMSTS: F0360H
b7 b6 b5 b4 b3 b2 b1 b0
— — — — — — RF1
MLT
RF0
MLT
After Reset 0 0 0 0 0 0 0 0
Bit Symbol Bit Name Description R/W
7 to 2 — Reserved These bits are always read as 0. R
1 RF1MLT Receive FIFO Buffer 1 Message
Lost Status Flag
0: No receive FIFO buffer m message is lost (m = 0, 1).
1: A receive FIFO buffer m message is lost.
R
0 RF0MLT Receive FIFO Buffer 0 Message
Lost Status Flag
R
The RFMSTS register is cleared to H'00 in global reset mode.
• RFmMLT Flag
The RFmMLT flag is set to 1 when the RFMLT flag in the RFSTSm register is set to 1 (a receive FIFO message
is lost). When the RFMLT flag is cleared to 0, the RFmMLT flag is cleared to 0.
