RL78/F13, F14 CHAPTER 5 CLOCK GENERATOR
R01UH0368EJ0210 Rev.2.10 388
Dec 10, 2015
5.3.10 CAN Clock Select Register (CANCKSEL)
This register is used to control the X1 clock (fx) supplied to the CAN.
Set the CANCKSEL register by a 1-bit or 8-bit memory manipulation instruction.
Writing to the CANCKSEL register is disabled when the GCSC bit of the IAWCTL register is set to 1.
Figure 5-17. Format of CAN Clock Select Register (CANCKSEL)
Address: F02C2H After reset: 00H R/W
Symbol 7 6 5 4 3 2 1 <0>
CANCKSEL 0 0 0
0 0 0 0
CAN0MCKE
Note
CAN0MCKE
Note
Control of supplying or stopping CAN X1 clock (fx)
0 Stops CAN X1 clock (fx) supply.
1 Enables CAN X1 clock (fx) supply.
Note Only in the RL78/F13 (CAN and LIN incorporated) and RL78/F14 products.
