RL78/F13, F14 CHAPTER 18 CAN INTERFACE (RS-CAN LITE)
R01UH0368EJ0210 Rev.2.10 1373
Dec 10, 2015
18.3.76 CANi Transmit History Buffer Access Register (THLACCi) (i = 0)
Address THLACC0L: F0680H, THLACC0H: F0681H
b15 b14 b13 b12 b11 b10 b9 b8 b7 b6 b5 b4 b3 b2 b1 b0
TID[7:0] — — — BN[1:0] — BT[1:0]
After Reset 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Bit Symbol Bit Name Description R/W
15 to 8 TID[7:0] Label Data The label information of stored data can be read. R
7 to 5 — Reserved These bits are always read as 0. R
4, 3 BN[1:0] Buffer Number Data The buffer number of transmit source (transmit buffer or
transmit/receive FIFO) can be read.
R
2 — Reserved This bit is always read as 0. R
1, 0 BT[1:0] Buffer Type Data
b1 b0
0 1 : Transmit buffer
1 0 : Transmit FIFO buffer
R
This register can be read when the RPAGE bit in the GRWCR register is 1.
• TID [7:0] Bits
These bits indicate the label information of transmit history data stored in the transmit history buffer.
• BN[1:0] Bits
These bits indicate the transmit source buffer number of transmit history data stored in the transmit history
buffer.
• BT[1:0] Bits
These bits indicate the transmit source buffer type of transmit history data stored in the transmit history buffer.
To Next Page
