RL78/F13, F14 CHAPTER 18 CAN INTERFACE (RS-CAN LITE)
R01UH0368EJ0210 Rev.2.10 1367
Dec 10, 2015
18.3.70 CANi Transmit Buffer Register pCL (TMDF0p) (i = 0) (p = 0 to 3)
Address TMDF00L: F0608H, TMDF00H: F0609H TMDF01L: F0618H, TMDF01H: F0619H
TMDF02L: F0628H, TMDF02H: F0629H TMDF03L: F0638H, TMDF03H: F0639H
b15 b14 b13 b12 b11 b10 b9 b8 b7 b6 b5 b4 b3 b2 b1 b0
TMDB1[7:0] TMDB0[7:0]
After Reset 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Bit Symbol Bit Name Description R/W
15 to 8 TMDB1[7:0] Transmit Buffer Data Byte 1 Set transmit buffer data. R/W
7 to 0 TMDB0[7:0] Transmit Buffer Data Byte 0 R/W
Modify this register when the TMTRM bit in the corresponding TMSTSp register is set to 0 (no transmit request is
present). If this register is linked to any transmit/receive FIFO buffer, do not write data to this register.
This register can be read/written when the RPAGE bit in the GRWCR register is 1.
