Renesas RL78 Series User Manual

RL78/F13, F14 CHAPTER 18 CAN INTERFACE (RS-CAN LITE)
R01UH0368EJ0210 Rev.2.10 1370
Dec 10, 2015
18.3.73 CANi Transmit Buffer Register pDH (TMDF3p) (i = 0) (p = 0 to 3)
Address TMDF30L: F060EH, TMDF30H: F060FH TMDF31L: F061EH, TMDF31H: F061FH
TMDF32L: F062EH, TMDF32H: F062FH TMDF33L: F063EH, TMDF33H: F063FH
b15 b14 b13 b12 b11 b10 b9 b8 b7 b6 b5 b4 b3 b2 b1 b0
TMDB7[7:0] TMDB6[7:0]
After Reset 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Bit Symbol Bit Name Description R/W
15 to 8 TMDB7[7:0] Transmit Buffer Data Byte 7 Set transmit buffer data. R/W
7 to 0 TMDB6[7:0] Transmit Buffer Data Byte 6 R/W
Modify this register when the TMTRM bit in the corresponding TMSTSp register is set to 0 (no transmit request is
present). If this register is linked to any transmit/receive FIFO buffer, do not write data to this register.
This register can be read/written when the RPAGE bit in the GRWCR register is 1.
