RL78/F13, F14 CHAPTER 8 TIMER RD
R01UH0368EJ0210 Rev.2.10 575
Dec 10, 2015
8.2.6 Timer RD PWM Function Select Register (TRDPMR)
Figure 8-7. Format of Timer RD PWM Function Select Register (TRDPMR) [Timer Mode]
Address: F0265H After Reset:00H
Note
Symbol 7 <6> <5> <4> 3 <2> <1> <0>
TRDPMR 0
TRDPWMD1 TRDPWMC1 TRDPWMB1 0 TRDPWMD0 TRDPWMC0 TRDPWMB0
TRDPWMD1 PWM function of TRDIOD1 select R/W
0 Input capture function or output compare function R/W
1 PWM function
TRDPWMC1 PWM function of TRDIOC1 select
R/W
0 Input capture function or output compare function R/W
1 PWM function
TRDPWMB1 PWM function of TRDIOB1 select
R/W
0 Input capture function or output compare function R/W
1 PWM function
TRDPWMD0 PWM function of TRDIOD0 select R/W
0 Input capture function or output compare function R/W
1 PWM function
TRDPWMC0 PWM function of TRDIOC0 select
R/W
0 Input capture function or output compare function R/W
1 PWM function
TRDPWMB0 PWM function of TRDIOB0 select
R/W
0 Input capture function or output compare function R/W
1 PWM function
Note The value after reset is undefined when FRQSEL4 = 1 in the user option byte (000C2H/020C2H) and TRD0EN
= 0 in the PER1 register. If it is necessary to read the initial value, set f
CLK to fIH and TRD0EN = 1 before
reading.
Bit 7 Nothing is assigned R/W
—
The write value must be 0. The read value is 0.
R
Bit 3 Nothing is assigned R/W
— The write value must be 0. The read value is 0. R
