RL78/F13, F14 CHAPTER 30 FLASH MEMORY
R01UH0368EJ0210 Rev.2.10 1637
Dec 10, 2015
Table 30-9. Example of Signature Data
Field name Description Number of transmit data Data (hexadecimal)
Device code RL78 protocol A 3 bytes 10 00 06
Device name R5F10BLE 10 bytes 52 = "R"
35 = "5"
46 = "F"
31 = "1"
30 = "0"
42 = "B"
4C = "L"
45 = "E"
20 = " "
20 = “ ”
Code flash memory area last address Code flash memory area
00000H to 0FFFFH (64 KB)
3 bytes FF FF 00
Data flash memory area last address Data flash memory area
F1000H to F1FFFH (4 KB)
3 bytes FF 1F 0F
Firmware version Ver.1.23 3 bytes 01 02 03
30.5 Processing Time for Each Command when PG-FP5 Is in Use (Reference Value)
The following shows the processing time for each command (reference value) when PG-FP5 is used as a dedicated flash
memory programmer.
Table 30-10. Processing Time for Each Command When PG-FP5 Is in Use (Reference Value)
PG-FP5 Command Code Flash
16 KB 32 KB 48 KB 64 KB 96 KB 128 KB 192 KB 256 KB
Erase 1 s 1 s 1 s 1.5 s 1.5 s 2 s 2 s 2.5 s
Write 1.5 s 1.5 s 2 s 2.5 s 3 s 3.5 s 5 s 6 s
Verify 1.5 s 1.5 s 2 s 2 s 3 s 3.5 s 4.5 s 5.5 s
Write after erase 1.5 s 2 s 2.5 s 3 s 4 s 4.5 s 6.5 s 8 s
Remark The command processing times (reference value) shown in the table are typical values under the following
conditions.
Port: TOOL0 (single-line UART)
Speed: 1,000,000 bps
