RL78/F13, F14 CHAPTER 13 D/A CONVERTER (RL78/F14 Only)

R01UH0368EJ0210 Rev.2.10 770

Dec 10, 2015

13.3.5 D/A Conversion Value Setting Register 0 (DACS0)

This register is used to set the analog voltage value to be output to the ANO0 pin when the D/A converter is used.

Set the DACS0 register by an 8-bit memory manipulation instruction.

Reset signal generation clears this register to 00H.

Figure 13-6. Format of D/A Conversion Value Setting Register 0 (DACS0)

Address: FFF34H After reset: 00H R/W

Symbol 7 6 5 4 3 2 1 0

DACS0 DACS07 DACS06 DACS05 DACS04 DACS03 DACS02 DACS01 DACS00

Remark The analog output voltage (VANO0) of the D/A converter is defined as follows.

VANO0 = Reference voltage for D/A converter × (DACS0)/256
