Renesas RL78 Series

RL78/F13, F14 CHAPTER 4 PORT FUNCTIONS
R01UH0368EJ0210 Rev.2.10 326
Dec 10, 2015
4.3.7 A/D port configuration register (ADPC)
This register is used to switch the P33/ANI0/AV
REFP, P34/ANI1/AVREFM, P80/ANI2/ANO0, P81/ANI3/IVCMP00 to
P84/ANI6/IVCMP03, P85/ANI7/IVREF0, and P86/ANI8 to P105/ANI23 pins to digital I/O of port or analog input of A/D
converter.
This register is also used to switch the P80/ANI2/ANO0 pins to digital I/O of port or analog output of D/A converter.
This register is also used to switch the P81/ANI3/IVCMP00 to P84/ANI6/IVCMP03 and P85/ANI7/IVREF0 pins to
analog input of comparator or digital I/O of port.
The ADPC register can be set by an 8-bit memory manipulation instruction.
Reset signal generation clears this register to 00H.
Figure 4-80. Format of A/D Port Configuration Register (ADPC) (100-pin products)
Address: F0076H After reset: 00H R/W
Symbol 7 6 5 4 3 2 1 0
ADPC 0 0 0 ADPC4 ADPC3 ADPC2 ADPC1 ADPC0
ADPC4 to ADPC0
ANI23/P105 ANI22/P104 ANI21/P103 ANI20/P102 ANI19/P101 ANI18/P100 ANI17/P97 ANI16/P96 ANI15/P95 ANI14/P94 ANI13/P93 ANI12/P92 ANI11/P91 ANI10/P90 ANI9/P87 ANI8/P86 ANI7/P85 ANI6/P84 ANI5/P83 ANI4/P82 ANI3/P81 ANI2/P80 ANI1/P34 ANI0/P33
0 0 0 0 0 A A A A A A A A A A A A A A A A A A A A A A A A
0 0 0 0 1 D D D D D D D D D D D D D D D D D D D D D D D D
0 0 0 1 0 D D D D D D D D D D D D D D D D D D D D D D D A
0 0 0 1 1 D D D D D D D D D D D D D D D D D D D D D D A A
0 0 1 0 0 D D D D D D D D D D D D D D D D D D D D D A A A
0 0 1 0 1 D D D D D D D D D D D D D D D D D D D D A A A A
0 0 1 1 0 D D D D D D D D D D D D D D D D D D D A A A A A
0 0 1 1 1 D D D D D D D D D D D D D D D D D D A A A A A A
0 1 0 0 0 D D D D D D D D D D D D D D D D D A A A A A A A
0 1 0 0 1 D D D D D D D D D D D D D D D D A A A A A A A A
0 1 0 1 0 D D D D D D D D D D D D D D D A A A A A A A A A
0 1 0 1 1 D D D D D D D D D D D D D D A A A A A A A A A A
0 1 1 0 0 D D D D D D D D D D D D D A A A A A A A A A A A
0 1 1 0 1 D D D D D D D D D D D D A A A A A A A A A A A A
0 1 1 1 0 D D D D D D D D D D D A A A A A A A A A A A A A
0 1 1 1 1 D D D D D D D D D D A A A A A A A A A A A A A A
1 0 0 0 0 D D D D D D D D D A A A A A A A A A A A A A A A
1 0 0 0 1 D D D D D D D D A A A A A A A A A A A A A A A A
1 0 0 1 0 D D D D D D D A A A A A A A A A A A A A A A A A
1 0 0 1 1 D D D D D D A A A A A A A A A A A A A A A A A A
1 0 1 0 0 D D D D D A A A A A A A A A A A A A A A A A A A
1 0 1 0 1 D D D D A A A A A A A A A A A A A A A A A A A A
1 0 1 1 0 D D D A A A A A A A A A A A A A A A A A A A A A
1 0 1 1 1 D D A A A A A A A A A A A A A A A A A A A A A A
1 1 0 0 0 D A A A A A A A A A A A A A A A A A A A A A A A
Other than above Setting prohibited
