Renesas RL78 Series

RL78/F13, F14 CHAPTER 4 PORT FUNCTIONS
R01UH0368EJ0210 Rev.2.10 327
Dec 10, 2015
Cautions 1. Set the channel used for A/D conversion to the input mode by using port mode registers 3, 8, 9,
10 (PM3, PM8, PM9, PM10).
2. Set the channel used for D/A conversion or comparator to the input mode by using port mode
registers 3, 8 (PM3, PM8).
3. Do not set the pin set by the ADPC register as digital I/O by the analog input channel
specification register (ADS).
4. Do not set the pin set by the ADPC register as digital I/O by D/A converter mode register (DAM)
as D/A conversion operation enable.
5. Do not set the pin set by the ADPC register as digital I/O by the comparator I/O select register
(CMPSEL).
