Renesas RL78 Series - DTC Block Size Register J (Dtblsj) (J = 0 to 23)

RL78/F13, F14 CHAPTER 19 DTC
R01UH0368EJ0210 Rev.2.10 1442
Dec 10, 2015
19.2.8 DTC Block Size Register j (DTBLSj) (j = 0 to 23)
This register is used to set the block size of the data to be transferred by one activation.
Figure 19-8. Format of DTC Block Size Register j (DTBLSj)
Address: Refer to 19.2.2 DTC Control Data Allocation. After reset: Undefined
Symbol 7 6 5 4 3 2 1 0
DTBLSj DTBLSj7 DTBLSj6 DTBLSj5 DTBLSj4 DTBLSj3 DTBLSj2 DTBLSj1 DTBLSj0
DTBLSj Transfer Block Size R/W
8-Bit Transfer 16-Bit Transfer
00H 256 bytes 512 bytes R/W
01H 1 byte 2 bytes
02H 2 bytes 4 bytes
03H 3 bytes 6 bytes
·
·
·
·
·
·
·
·
·
FDH 253 bytes 506 bytes
FEH 254 bytes 508 bytes
FFH 255 bytes 510 bytes
Caution Do not access the DTBLSj register using a DTC transfer.
19.2.9 DTC Transfer Count Register j (DTCCTj) (j = 0 to 23)
This register is used to set the number of DTC data transfers. The value is decremented by 1 each time DTC transfer is
activated once.
Figure 19-9. Format of DTC Transfer Count Register j (DTCCTj)
Address: Refer to 19.2.2 DTC Control Data Allocation. After reset: Undefined
Symbol 7 6 5 4 3 2 1 0
DTCCTj DTCCTj7 DTCCTj6 DTCCTj5 DTCCTj4 DTCCTj3 DTCCTj2 DTCCTj1 DTCCTj0
DTCCTj Number of Transfers R/W
00H 256 times R/W
01H Once
02H 2 times
03H 3 times
·
·
·
·
·
·
FDH 253 times
FEH 254 times
FFH 255 times
Caution Do not access the DTCCTj register using a DTC transfer.
