Renesas RL78 Series User Manual

RL78/F13, F14 CHAPTER 5 CLOCK GENERATOR
R01UH0368EJ0210 Rev.2.10 365
Dec 10, 2015
5.2 Configuration of Clock Generator
The clock generator includes the following hardware.
Table 5-1. Configuration of Clock Generator
Item Configuration
Control registers Clock operation mode control register (CMC)
System clock control register (CKC)
Clock operation status control register (CSC)
Oscillation stabilization time counter status register (OSTC)
Oscillation stabilization time select register (OSTS)
Peripheral enable registers 0, 1, 2 (PER0, PER1, PER2)
Operation speed mode control register (OSMC)
High-speed on-chip oscillator frequency select register (HOCODIV)
High-speed on-chip oscillator trimming register (HIOTRM)
CAN clock select register (CANCKSEL)
LIN clock select register (LINCKSEL)
Clock select register (CKSEL)
PLL control register (PLLCTL)
PLL status register (PLLSTS)
f
MP clock division register (MDIV)
Oscillators X1 oscillator
XT1 oscillator
High-speed on-chip oscillator clock
Low-speed on-chip oscillator clock

Renesas RL78 Series Specifications

General

Core	RL78
CPU Clock Speed	Up to 32 MHz
Flash Memory	Up to 512 KB
RAM	Up to 32 KB
Operating Voltage	1.6 V to 5.5 V
Low Power Modes	HALT, STOP, SNOOZE
CPU Architecture	16-bit
Temperature Range	-40°C to +85°C
Package	LQFP
Timers	16-bit timers
Communication Interfaces	UART, I2C, LIN
A/D Converter	12-bit
