RL78/F13, F14 CHAPTER 5 CLOCK GENERATOR
R01UH0368EJ0210 Rev.2.10 393
Dec 10, 2015
5.3.14 PLL Status Register (PLLSTS)
This register is used to indicate the operation status of the PLL clock.
Read the PLLSTS register by a 1-bit or 8-bit memory manipulation instruction.
Reset signal generation sets this register to 00H.
Figure 5-21. Format of PLL Status Register (PLLSTS)
Address: F02C6H After reset: 00H R
Symbol <7> 6 5 4 <3> 2 1 0
PLLSTS LOCK 0 0
0 SELPLLS 0 0 0
LOCK PLL locked state
0 Unlocked state
1
Note
Locked state
This bit is set to 1 when the lock-up wait counter overflows.
SELPLLS CLock mode state
0 Clock through mode (fMAIN)
1 PLL-clock-selected mode (fPLL)
Note When PLL operation starts, a wait time for the PLL to be locked (LOCK = 1) is required.

Renesas RL78 Series Specifications

General

Core	RL78
CPU Clock Speed	Up to 32 MHz
Flash Memory	Up to 512 KB
RAM	Up to 32 KB
Operating Voltage	1.6 V to 5.5 V
Low Power Modes	HALT, STOP, SNOOZE
CPU Architecture	16-bit
Temperature Range	-40°C to +85°C
Package	LQFP
Timers	16-bit timers
Communication Interfaces	UART, I2C, LIN
A/D Converter	12-bit
