RL78/F13, F14 CHAPTER 1 OVERVIEW

R01UH0368EJ0210 Rev.2.10 4

Dec 10, 2015

1.3 Function Overview

1.3.1 RL78/F14 Functions List

Table 1-4. RL78/F14 Functions List (1/2)

Series Name R5F10PP R5F10PM R5F10PL R5F10PG R5F10PB R5F10PA

Pin Count 100 pins 80 pins 64 pins 48 pins 32 pins 30 pins

Code flash 64 to 256KB 48 to 256KB 48KB, 64KB

Data flash 8KB/4KB 4KB

RAM 6 to 20KB 4 to 20KB 48KB, 64KB

Supply voltage range 2.7 V to 5.5 V

Maximum operation frequency 32 MHz (grade L), 24 MHz (grade K, grade Y)

System clock

Main system

clock oscillator

Crystal/ceramic/

square wave

1 to 20 MHz (operating at 2.7 V to 5.5 V)

High-speed on-

chip oscillator

Normal high accuracy 32 MHz (typ.)

Low-speed on-

chip oscillator

For low-speed operation 15 kHz (typ.)

Subsystem clock oscillator 32.768 kHz

Note 7

None

PLL PLL multiplication factor: 3/4/6/8

Clock for

peripherals

Low-speed on-

chip oscillator

For peripherals other

than WDT

15 kHz (typ.)

For WDT 15 kHz (typ.)

POR

When power supply

is rising

1.56 V (typ.)

When power supply

is falling

1.55 V (typ.)

LVD VDD voltage

detection

When power supply

is rising

2.81 V (typ.) to 4.74 V (typ.) (in 6 steps)

When power supply

is falling

2.75 V (typ.) to 4.64 V (typ.) (in 6 steps)

Safety functions WWDT (window watchdog timer) Yes

Illegal instruction execution detection

function

Yes

Flash memory CRC operation function Yes

RAM1 bit error correction function Yes

RAM2 bit error detection function Yes

Invalid memory access detection function Yes

Frequency detection function Yes

Clock monitor function Yes

Stack pointer monitor function Yes

I/O port output signal level detection function

Yes

A/D test function Yes

I/O ports Input/Output CMOS 86ch 68ch 52ch 38ch 25ch 23ch

Output CMOS 1ch None

Input

Shared with oscillator pins

4ch

Note 7

2ch

Input only

1ch

Power supply

pins

For internal circuits VDD, VSS, REGC

For I/O ports

EVDD0, EVSS0

EVDD1, EVSS1

EVDD0, EVSS0 None

For analog circuits (AD, DA, COMP) VDD, VSS (AVREFP, AVREFM: For AD)

Multiply/divide

and multiply-

accumulate

functions

Multiply 16 bits  16 bits (signed)

16 bits  16 bits (unsigned)

Divide 32 bits  32 bits (unsigned)

Multiply-accumulate 16 bits  16 bits + 32 bits (signed)

16 bits  16 bits + 32 bits (unsigned)

Arithmetic instructions

(extended instruction set)

Yes

Vectored

interrupt

sources

External Products with at least

128 Kbytes of code flash

memory

16ch

Notes 4, 6

16ch

Notes 4, 6

15ch

Notes 3, 6

14ch

Note 2

9ch

Note 1

Products with up to 96

Kbytes of code flash

memory

14ch

Notes 3, 5

14ch

Notes 3, 5

13ch

Note 2

Internal Products with at least

128 Kbytes of code flash

memory

48ch

Note 4

48ch

Note 4

48ch

Note 3

48ch

Note 2

41ch

Note 1

40ch

Note 1

Products with up to 96

Kbytes of code flash

memory

41ch

Note 3

41ch

Note 3

41ch

Note 2

Key return detection 8ch 6ch 8ch

DTC

44 sources

44 sources/38 sources 37 sources

Timer TAU

16 bits

(8ch  2)

16 bits (8ch  2/8ch + 4ch) 16 bits (8ch + 4ch)

RTC 1ch

Timer RJ 16 bits  1

Timer RD 16 bits  2

Serial I/F CSI/simplified I

C /UART 4ch/4ch/2ch 3ch/3ch/2ch

SPI Yes

Multimaster I

C 1ch None

LIN/UART module (RLIN3) 2ch 2ch/1ch 1ch

CAN interface (RS-CAN lite) 1ch

(Notes and Caution are listed on the next page.)
