Renesas RL78 Series User Manual

RL78/F13, F14 CHAPTER 20 EVENT LINK CONTROLLER (ELC) (RL78/F14 Only)
R01UH0368EJ0210 Rev.2.10 1467
Dec 10, 2015
20.2 Registers
Table 20-1 lists the ELC register configuration.
Table 20-1. ELC Register Configuration
Register name Symbol After Reset Address Access size
Event Output Destination Select Register 00 ELSELR00 00H F0780H 1, 8
Event Output Destination Select Register 01 ELSELR01 00H F0781H 1, 8
Event Output Destination Select Register 02 ELSELR02 00H F0782H 1, 8
Event Output Destination Select Register 03 ELSELR03 00H F0783H 1, 8
Event Output Destination Select Register 04 ELSELR04 00H F0784H 1, 8
Event Output Destination Select Register 05 ELSELR05 00H F0785H 1, 8
Event Output Destination Select Register 06 ELSELR06 00H F0786H 1, 8
Event Output Destination Select Register 07 ELSELR07 00H F0787H 1, 8
Event Output Destination Select Register 08 ELSELR08 00H F0788H 1, 8
Event Output Destination Select Register 09 ELSELR09 00H F0789H 1, 8
Event Output Destination Select Register 10 ELSELR10 00H F078AH 1, 8
Event Output Destination Select Register 11 ELSELR11 00H F078BH 1, 8
Event Output Destination Select Register 12 ELSELR12 00H F078CH 1, 8
Event Output Destination Select Register 13 ELSELR13 00H F078DH 1, 8
Event Output Destination Select Register 14 ELSELR14 00H F078EH 1, 8
Event Output Destination Select Register 15 ELSELR15 00H F078FH 1, 8
Event Output Destination Select Register 16 ELSELR16 00H F0790H 1, 8
Event Output Destination Select Register 17 ELSELR17 00H F0791H 1, 8
Event Output Destination Select Register 18 ELSELR18 00H F0792H 1, 8
Event Output Destination Select Register 19 ELSELR19 00H F0793H 1, 8
Event Output Destination Select Register 20
Note
ELSELR20 00H F0794H 1, 8
Event Output Destination Select Register 21
Note
ELSELR21 00H F0795H 1, 8
Event Output Destination Select Register 22
Note
ELSELR22 00H F0796H 1, 8
Event Output Destination Select Register 23
Note
ELSELR23 00H F0797H 1, 8
Event Output Destination Select Register 24
Note
ELSELR24 00H F0798H 1, 8
Event Output Destination Select Register 25
Note
ELSELR25 00H F0799H 1, 8
Note For Group E products only.
