RL78/F13, F14 CHAPTER 7 TIMER RJ

R01UH0368EJ0210 Rev.2.10 554

Dec 10, 2015

7.3.8 Timer RJ Event Pin Select Register 0 (TRJISR0)

Figure 7-9. Format of Timer RJ Event Pin Select Register 0 (TRJISR0)

Address : F0243H After Reset: 00H

Symbol 7 6 5 4 3 2 1 0

TRJISR0 —

— — — —

RCCPSEL2

Note

RCCPSEL1

Note

RCCPSEL0

Note

Bit 7 to

Nothing is assigned R/W

— The write value must be 0. The read value is 0. R

RCCPS

EL2

Timer output signal and INTP4 polarity selection

R/W

0 An event is counted during the low-level period R/W

1 An event is counted during the high-level period

RCCPS

EL1

RCCPS

EL0

Timer output signal selection R/W

0 0 TRDIOD1 R/W

0 1 TRDIOC1

1 0 TO02

1 1 TO03

Note Bits RCCPSEL0 to RCCPSEL2 are enabled only in event counter mode.

Caution The 20-pin products do not have the timer RJ event pin select register 0 (TRJISR0).
