RL78/F13, F14 CHAPTER 15 SERIAL ARRAY UNIT

R01UH0368EJ0210 Rev.2.10 975

Dec 10, 2015

(3) Processing flow

Figure 15-133. Timing Chart of UART Reception

Remark m: Unit number (m = 0, 1), n: Channel number (n = 1), mn = 01, 11, r: Channel number (r = n − 1),

q: UART number (q = 0, 1)

SSmn

SEmn

SDRmn

RxDq pin

Shift

INTSRq

TSFmn

ST ST

STmn

Data reception (7-bit length)

Receive data 1

Receive data 2

Receive data 3

Receive data 2

Receive data 1

Shift operation

Receive data 3
