Renesas RL78 Series User Manual

RL78/F13, F14 CHAPTER 17 LIN/UART MODULE (RLIN3)
R01UH0368EJ0210 Rev.2.10 1103
Dec 10, 2015
Item Specifications
LIN
communication
function
Status Slave
 Successful frame/wake-up transmission
 Successful frame/wake-up reception
Note 2
 Successful header reception
 Successful data 1 reception
 Error detection
 Operation mode
(LIN reset mode, LIN wake-up mode, LIN operation mode, LIN self-test mode)
Error status Master
 Bit error
 Checksum error
 Frame timeout error/response timeout error
 Physical bus error
 Framing error
 Response preparation error
Slave
 Bit error
 Checksum error
 Frame timeout error/response timeout error
 Sync field error
 ID parity error
 Framing error
 Response preparation error
Baud rate
selection
Baud rate conforming to the LIN specifications generated using baud rate generator
Test mode Self-test mode for user evaluation
Interrupt
function
Master
 Successful header/frame/wake-up transmission
 Successful frame/wake-up reception
Note 2
 Error detection
Slave
 Successful frame/wake-up transmission
 Header/frame/wake-up reception
Note 2
 Error detection

Renesas RL78 Series Specifications

General

Core	RL78
CPU Clock Speed	Up to 32 MHz
Flash Memory	Up to 512 KB
RAM	Up to 32 KB
Operating Voltage	1.6 V to 5.5 V
Low Power Modes	HALT, STOP, SNOOZE
CPU Architecture	16-bit
Temperature Range	-40°C to +85°C
Package	LQFP
Timers	16-bit timers
Communication Interfaces	UART, I2C, LIN
A/D Converter	12-bit
